Vitrum EU III ON-OFF Cloud

€296.36

SKU: 01E03H020 Category: Brand:

Vitrum EU III ON-OFF is a Z-Wave switch with 3 relays. It can be combined with the Vitrum Design Frame. Vitrum Design offers intuitive operation thanks to the RGB backlight and acoustic feedback of each button. Each button can be assigned an individual pictogram to make operation even easier. The output of the ON-OFF switch is a dry contact. Each button can be configured individually via the Z-Wave controller, allowing you to control various devices via associations and scenes.
Features

  • Built-in unit for Vitrum Design Frame
  • Z-Wave switch
  • Maximum load per output is 16A
  • Extended association groups
Built-in box

503 Italian Standard (74,0 x 107,0 x 51,3 mm)

Communicatie & Protocol

Z-Wave

IP value

IP20

Integrated LED ring

RGB

Maximum load capacity

16A

Operating humidity

20% – 90% relative humidity

Operating temperature

0–40°C

Outputs

3

Power Factor

cos(Φ) 0,6 inductive , cos(Φ) 0,9 resistive

Power source

230V AC, 50/60 Hz

Protocol

Z-Wave Plus

Standby consumption

< 1,5W
