Shelly 1PM Gen4

The Shelly 1PM Gen4 is a compact smart switch with integrated power metering. It allows you to control electrical appliances remotely and monitor energy consumption in real time via your smartphone, tablet, PC or home automation system. The device works standalone in a local Wi-Fi network or through cloud-based automation services. This new generation is the improved successor to the Shelly 1PM Gen3 and now features Zigbee connectivity and is Matter certified. Thanks to its small form factor, the Shelly 1PM Gen4 is perfect for installation in standard wall boxes, behind power outlets or switches, and in other tight spaces. The device has a built-in web interface for adjusting settings, monitoring power usage and direct control. The integrated wireless chip supports multiple protocols (Zigbee, Wi-Fi and Bluetooth) to ensure a stable and secure connection. Shelly 1PM Gen4 is compatible with Matter over Wi-Fi. Supported load types

• Resistive (Ohmic) – Incandescent bulbs, halogen lamps, heating appliances
• Capacitive – Electronic devices with capacitors
• Inductive (with RC Snubber) – LED lighting, LED drivers, air conditioners and fans

Note! The inrush current of inductive loads like LED lighting can damage the relay. Use an RC Snubber to absorb the inrush current.
Features

• Wi-Fi connectivity
• Zigbee
• Matter (over Wi-Fi)
• Bluetooth (for connecting Shelly devices)
• Local and cloud control
• Integration with Smart Home platforms: Easily integrate with Home Assistant and Homey Pro
• Also compatible with Google Home, Alexa, Apple Home and Samsung SmartThings for voice control and automation
• User-friendly interface
• Relay 1x – Max. 16A at 230V AC or Max. 10A at 30V DC
• Power supply: 24–30V DC or 110–230V AC
• Power metering
• 37x42x16mm
• BLE Gateway: Bridge between your Shelly BLU devices and the wider Shelly ecosystem. Receives Bluetooth signals and sends them to the cloud or locally to a non-Bluetooth device
• Wi-Fi extender for Shelly IoT devices: Expands your Wi-Fi range by boosting and redistributing your current signal
• Scripting: Shelly Scripting Language Features
• Broad integration options: Compatible with third-party systems via HTTP API, MQTT(s), Web Hooks (HTTP/HTTPS), UDP
• KNX: Supports KNXnet/IP communication
• Virtual Components: Virtual Components
